ASUS ROG Strix X870E-A Gaming WiFi7 Neo DDR5 AMD Motherboard
Ā
Elevate your build with the ROG Strix X870E-A Gaming WiFi7 Neo, featuring a sleek white aesthetic and a design that maximizes the performance of AMD Ryzenā¢ 9000 Series processors. PCIeĀ®Ā 5.0, ASUS AI features including AI Cache Boost and ASUS AI Advisorāand exclusive memory technologies such as NitroPath DRAM Technology, DIMM Fit Pro, and AEMPāsimplify setup and deliver optimized DDR5 performance. High-speed connectivity is boosted by dual USB4Ā®Ā Type-C ports, WiFi 7, and RealtekĀ®Ā 5G Ethernet, while enhanced M.2 cooling helps ensure stability for demanding workloads. It is the ultimate blend of style and performance.
Ā
| CORE SPECIFICATIONS | |
|---|---|
| Model | ROG STRIX X870E-A GAMING WIFI7 NEO |
| CPU Socket | AMD AM5 (Supports Ryzen 9000, 8000, & 7000 Series) |
| Chipset | AMD X870E |
| Memory | 4 x DDR5 DIMM (Max 256GB), Supports EXPO, NitroPath, and AEMP |
| Form Factor | ATX (12" x 9.6") |
| EXPANSION & STORAGE | |
| PCIe Slots | 1 x PCIe 5.0 x16 (Ryzen 9000/7000), 1 x PCIe 4.0 x16 (Chipset) |
| M.2 Slots | 4 x Total (2 x PCIe 5.0, 2 x PCIe 4.0) |
| SATA | 4 x SATA 6Gb/s |
| CONNECTIVITY & AUDIO | |
| Ethernet | Realtek 5Gb Ethernet |
| Wireless | Wi-Fi 7 (MediaTek MT7925), Bluetooth 5.4 |
| Rear USB | 2 x USB4 (40Gbps), 6 x USB 10Gbps, 4 x USB 5Gbps |
| Audio | ROG SupremeFX ALC4080 7.1 Surround (Savitech SV3H712 AMP) |
| INTERNAL HEADERS | |
| Fan/Cooling | CPU, CPU OPT, AIO Pump, 5 x Chassis Fan headers |
| USB Headers | 1 x USB 20Gbps (Type-C), 1 x USB 5Gbps (Type-C), 2 x USB 5Gbps, 3 x USB 2.0 |
| RGB | 3 x Addressable Gen 2 headers |
| SPECIAL FEATURES | |
| ASUS Q-Design | Q-Antenna, Q-Dashboard, Q-LED, PCIe/M.2 Q-Release/Latch/Slide |
| Cooling/DIY | VRM/M.2 heatsinks, BIOS FlashBack, Clear CMOS, ProCool II |
Ā
Original: $446.42
-70%$446.42
$133.93Product Information
