Intel Core Ultra 5 225 Processor

Unparalleled performance

The Intel Core Ultra 5 225 S-1851 has a boost frequency of 4.9 GHz, delivering blazing-fast speeds suited to demanding applications. With 10 cores and 10 threads, this CPU is designed to handle complex tasks, so productivity and entertainment run smoothly.

Advanced multitasking

This processor is equipped with a substantial 20MB cache that optimizes data access and processing, significantly reducing latency. This improvement provides a seamless multitasking environment, ensuring that applications and operations run smoothly without lag, which is crucial in both professional and gaming environments.

Superior onboard graphics

The integrated Intel graphics card delivers superb visual performance, rendering detailed graphics and high-resolution content effortlessly. Whether you're gaming or working with graphics-intensive applications, you can expect a vivid and immersive visual experience that elevates your computing activities.

Efficient power management

Designed for socket 1851, the Intel Core Ultra 5 efficiently manages power distribution, ensuring optimal performance while keeping energy consumption low. This balance of power and efficiency not only reduces energy costs, but also helps extend the lifespan of the processor.

Ideal for Business and Gaming

This processor belongs to the Core Ultra 5 family, making it a versatile choice for various applications - whether you're building powerful computing systems for businesses or creating a

High-performance gaming rig. Experience the combination of reliability and superior processing power tailored to meet modern demands.

SPECIFICATION

Essentials
Product Collection	Intel® Core™ Ultra Processors
Vertical Segment	Desktop
Processor Number	225
Overall Peak TOPS (Int8)	23
CPU Specifications
Total Cores	10
# of Performance-cores	6
# of Efficient-cores	4
Total Threads	10
Max Turbo Frequency	4.9 GHz
Performance-core Max Turbo Frequency	4.9 GHz
Efficient-core Max Turbo Frequency	4.4 GHz
Performance-core Base Frequency	3.3 GHz
Efficient-core Base Frequency	2.7 GHz
Cache	20 MB Intel® Smart Cache
Total L2 Cache	22 MB
Processor Base Power	65 W
Maximum Turbo Power	121 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
AI Software Frameworks Supported by CPU	OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography	TSMC N3B
Memory Specifications
Max Memory Size (dependent on memory type)	192 GB
Memory Types	Up to DDR5 6400 MT/s
Max # of Memory Channels	2
GPU Specifications
GPU Name‡	Intel® Graphics
Graphics Base Frequency	300 MHz
Graphics Max Dynamic Frequency	1.8 GHz
GPU Peak TOPS (Int8)	4
Graphics Output	DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
Xe-cores	2
Max Resolution (HDMI)‡	4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL)
Max Resolution (DP)‡	8K @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡	4K @ 60Hz
DirectX* Support	12
OpenGL* Support	4.5
OpenCL* Support	3
Intel® Quick Sync Video	Yes
# of Displays Supported ‡	4
Device ID	0x7D67
Intel® Deep Learning Boost (Intel® DL Boost) on GPU	Yes
NPU Specifications
NPU Name‡	Intel® AI Boost
NPU Peak TOPS (Int8)	13
Sparsity Support	Yes
Windows Studio Effects Support	Yes
AI Software Frameworks Supported by NPU	OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
Expansion Options
Direct Media Interface (DMI) Revision	4
Max # of DMI Lanes	8
Intel® Thunderbolt™ 4	Yes
Scalability	1S Only
PCI Express Revision	5.0 and 4.0
PCI Express Configurations ‡	Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
Max # of PCI Express Lanes	24
Package Specifications
Sockets Supported	FCLGA1851
Thermal Solution Specification	PCG 2022C
Max Operating Temperature	105 °C
Advanced Technologies
Intel® Volume Management Device (VMD)	Yes
Intel® Gaussian & Neural Accelerator	3.5
Intel® Thread Director	Yes
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Technology ‡	2
Intel® 64 ‡	Yes
Instruction Set	64-bit
Instruction Set Extensions	Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States	Yes
Enhanced Intel SpeedStep® Technology	Yes
Thermal Monitoring Technologies	Yes
Security & Reliability
Intel® Standard Manageability (ISM) ‡	Yes
Intel® Control-Flow Enforcement Technology	Yes
Intel® AES New Instructions	Yes
Secure Key	Yes
Intel® Trusted Execution Technology ‡	Yes
Execute Disable Bit ‡	Yes
Intel® OS Guard	Yes
Intel® Boot Guard	Yes
Mode-based Execute Control (MBEC)	Yes
Intel® Virtualization Technology (VT-x) ‡	Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡	Yes
Intel® VT-x with Extended Page Tables (EPT) ‡	Yes
