Kingston Fury Beast 64GB (2X32GB) DDR5 XMP 6000MT/S CL30 Memory (White) (KF560C30BWEK2-64)
Kingston FURY KF560C30BWEK2-64 is a kit of two 4G x 64-bit (32GB) DDR5-6000 CL30 SDRAM (Synchronous DRAM) 2Rx8, memory module, based on sixteen 2G x 8-bit FBGA components per module. Each module kit supports AMDĀ® EXPO v1.1 and IntelĀ® Extreme Memory Profiles (IntelĀ® XMP) 3.0. Total kit capacity is 64GB. Each module has been tested to run at DDR5-6000 at a low latency timing of 30-36-36 at 1.4V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers.
Features:
ā¢ Power Supply: VDD = 1.1V Typical
ā¢ VDDQ = 1.1V Typical
ā¢ VPP = 1.8V Typical
ā¢ VDDSPD = 1.8V to 2.0V
ā¢ On-Die ECC
ā¢ Height 1.37ā (34.9mm), w/heatsink
Ā
Specification:
| CL(IDD) | 40 cycles |
|---|---|
| Row Cycle Time (tRCmin) | 48ns (min.) |
| Refresh to Active/Refresh Command Time (tRFCmin) | 295ns (min.) |
| Row Active Time (tRASmin) | 32ns (min.) |
| UL Rating | 94 V - 0 |
| Operating Temperature | 0Ā°C to +85Ā°C |
| Storage Temperature | -55Ā°C to +100Ā°C |
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Kingston FURY KF560C30BWEK2-64 is a kit of two 4G x 64-bit (32GB) DDR5-6000 CL30 SDRAM (Synchronous DRAM) 2Rx8, memory module, based on sixteen 2G x 8-bit FBGA components per module. Each module kit supports AMDĀ® EXPO v1.1 and IntelĀ® Extreme Memory Profiles (IntelĀ® XMP) 3.0. Total kit capacity is 64GB. Each module has been tested to run at DDR5-6000 at a low latency timing of 30-36-36 at 1.4V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers.
Features:
ā¢ Power Supply: VDD = 1.1V Typical
ā¢ VDDQ = 1.1V Typical
ā¢ VPP = 1.8V Typical
ā¢ VDDSPD = 1.8V to 2.0V
ā¢ On-Die ECC
ā¢ Height 1.37ā (34.9mm), w/heatsink
Ā
Specification:
| CL(IDD) | 40 cycles |
|---|---|
| Row Cycle Time (tRCmin) | 48ns (min.) |
| Refresh to Active/Refresh Command Time (tRFCmin) | 295ns (min.) |
| Row Active Time (tRASmin) | 32ns (min.) |
| UL Rating | 94 V - 0 |
| Operating Temperature | 0Ā°C to +85Ā°C |
| Storage Temperature | -55Ā°C to +100Ā°C |
