PNY CS1031 500GB M.2 2280 NVME PCIE GEN3 X4 SSD (M280CS1031-500-CL)

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6

PNY CS1031 500GB M.2 2280 NVME PCIE GEN3 X4 SSD (M280CS1031-500-CL)

Specification

Usable Capacities 500GB
NAND Components 3D NAND
Interface PCIe Gen 3x4 NVMe 1.3
Form Factor M.2 2280
Package Dimensions (L×W×H) 123 x 85 x 4.3 mm
Product Dimensions (L×W×H) 22 x 80 x 2 mm
Weight 6.6g
Max Sequential Read* 500G: Up to 2200MB/s
Max Sequential Write* 500GB: up to 1200MB/s
TBW 500GB: 110
PCIe Link Power Management APST, ASPM, L1.2
Operating Temperature 0°C to 70°C
Storage Temperature  -40°C to 85°C
Certifications BSMI, CE, FCC, KCC, VCCI, REACH, RoHS
MTBF 2 Million Hours
Error Correction Code Less than 1 sector per ten quadrillion bits read
Product Health Monitoring Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T)
Full End-to-End Data path protection Supported
Performance Optimization TRIM (requires OS support)
$8.05

Original: $26.83

-70%
PNY CS1031 500GB M.2 2280 NVME PCIE GEN3 X4 SSD (M280CS1031-500-CL)—

$26.83

$8.05

Product Information

Shipping & Returns

Description

Specification

Usable Capacities 500GB
NAND Components 3D NAND
Interface PCIe Gen 3x4 NVMe 1.3
Form Factor M.2 2280
Package Dimensions (L×W×H) 123 x 85 x 4.3 mm
Product Dimensions (L×W×H) 22 x 80 x 2 mm
Weight 6.6g
Max Sequential Read* 500G: Up to 2200MB/s
Max Sequential Write* 500GB: up to 1200MB/s
TBW 500GB: 110
PCIe Link Power Management APST, ASPM, L1.2
Operating Temperature 0°C to 70°C
Storage Temperature  -40°C to 85°C
Certifications BSMI, CE, FCC, KCC, VCCI, REACH, RoHS
MTBF 2 Million Hours
Error Correction Code Less than 1 sector per ten quadrillion bits read
Product Health Monitoring Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T)
Full End-to-End Data path protection Supported
Performance Optimization TRIM (requires OS support)
